型號 | 壓縮機 | 蒸發-15℃ | 蒸發-10℃ | 蒸發-5℃ | 蒸發-0℃ | 蒸發+5℃ | |||||||
匹數 | 型號 | 數量 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | |
JX220SM | 20 | 4VES-10 | 2 | 25.30 | 11.90 | 32.00 | 12.96 | 40.60 | 13.88 | 49.20 | 14.64 | 59.80 | 15.26 |
JX224SM | 24 | 4TES-12 | 2 | 31.10 | 14.26 | 38.95 | 15.60 | 49.50 | 16.76 | 59.50 | 17.74 | 72.00 | 18.52 |
JX230SM | 30 | 4PES-15 | 2 | 36.50 | 16.90 | 45.90 | 18.86 | 57.10 | 20.58 | 70.30 | 22.02 | 84.20 | 23.08 |
JX240SM | 40 | 4NES-20 | 2 | 45.20 | 20.50 | 56.10 | 22.70 | 69.40 | 24.64 | 84.60 | 26.24 | 101.80 | 27.40 |
JX345SM | 45 | 4PES-15 | 3 | 54.10 | 25.35 | 69.00 | 28.29 | 85.30 | 30.87 | 104.50 | 33.03 | 125.90 | 34.62 |
JX250SM | 50 | 4HE-25 | 2 | 58.40 | 25.56 | 72.20 | 28.04 | 90.10 | 30.28 | 109.60 | 32.28 | 132.10 | 34.04 |
JX260SM | 60 | 4GE-30 | 2 | 67.10 | 30.28 | 83.60 | 33.14 | 103.20 | 35.78 | 125.80 | 38.18 | 151.00 | 40.20 |
JX360SM | 60 | 4NES-20 | 3 | 66.90 | 30.75 | 83.90 | 34.05 | 104.00 | 36.96 | 126.60 | 39.36 | 151.90 | 41.10 |
JX375SM | 75 | 4HE-25 | 3 | 86.20 | 38.34 | 109.00 | 42.06 | 135.40 | 45.42 | 164.00 | 48.42 | 197.40 | 51.06 |
JX390SM | 90 | 4GE-30 | 3 | 99.60 | 45.42 | 125.00 | 49.71 | 155.10 | 53.67 | 188.20 | 57.27 | 226.40 | 60.30 |
JX4100SM | 100 | 4HE-25 | 4 | 115.00 | 51.12 | 145.06 | 56.08 | 180.30 | 60.56 | 218.60 | 64.56 | 263.20 | 68.08 |
JX3105SM | 105 | 6HE-35 | 3 | 129.80 | 57.57 | 163.10 | 63.00 | 202.60 | 68.10 | 246.00 | 72.60 | 296.10 | 76.80 |
JX4120SM | 120 | 4GE-30 | 4 | 132.60 | 60.56 | 166.70 | 66.28 | 206.10 | 71.56 | 250.90 | 76.36 | 301.80 | 80.40 |
JX3120SM | 120 | 6GE-40 | 3 | 149.20 | 68.10 | 187.30 | 74.70 | 232.00 | 80.40 | 282.30 | 85.80 | 339.30 | 90.60 |
JX4140SM | 140 | 6HE-35 | 4 | 172.50 | 76.76 | 217.60 | 84.00 | 270.00 | 90.80 | 328.00 | 96.80 | 394.60 | 102.40 |
JX3150SM | 150 | 6FE-50 | 3 | 177.50 | 84.90 | 222.40 | 93.00 | 274.30 | 100.20 | 333.20 | 106.80 | 400.10 | 112.80 |
JX4160SM | 160 | 6GE-40 | 4 | 198.80 | 90.80 | 249.50 | 99.60 | 309.10 | 107.20 | 376.20 | 114.40 | 452.20 | 120.80 |
JX5175SM | 175 | 6HE-35 | 5 | 215.60 | 95.95 | 271.80 | 105.00 | 337.60 | 113.50 | 409.80 | 121.00 | 493.60 | 128.00 |
JX4200SM | 200 | 6FE-50 | 4 | 236.80 | 113.20 | 296.20 | 124.00 | 366.10 | 133.60 | 444.10 | 142.40 | 533.00 | 150.40 |
JX6210SM | 210 | 6HE-35 | 6 | 258.70 | 115.14 | 326.00 | 126.00 | 404.90 | 136.20 | 491.60 | 145.20 | 591.80 | 153.60 |
JX5250SM | 250 | 6FE-50 | 5 | 295.60 | 141.50 | 370.40 | 155.00 | 457.60 | 167.00 | 554.20 | 178.00 | 666.10 | 188.00 |
JX6300SM | 300 | 6FE-50 | 6 | 654.80 | 169.80 | 444.10 | 186.00 | 548.50 | 200.40 | 665.60 | 216.60 | 799.40 | 225.60 |
型號 | 機組對外管路尺寸 | 標準支管理球閥數量 | 外形尺寸 | 電子低液位報警 | 重量 | 電氣參數 | 機房通風量 | |||||||
排氣 | 供液 | 吸氣 | 排氣 | 供液 | 吸氣 | 長 | 寬 | 高 | 最大工作電流 | 保險絲電流 | m³/h | |||
mm | mm | mm | mm | mm | mm | mm | mm | mm | 有N/無N | kg | ||||
JX220SM | 28 | 22 | 54 | 1 | 1 | 0 | 1450 | 850 | 1650 | N | 500 | 28 | 35 | 2400 |
JX224SM | 28 | 22 | 54 | 1 | 1 | 0 | 1450 | 850 | 1650 | N | 500 | 34 | 43 | 2800 |
JX230SM | 35 | 28 | 54 | 1 | 1 | 0 | 1450 | 850 | 1650 | N | 500 | 41 | 51 | 3400 |
JX240SM | 35 | 28 | 67 | 1 | 1 | 0 | 1450 | 850 | 1650 | N | 500 | 48 | 60 | 4200 |
JX345SM | 42 | 35 | 67 | 1 | 1 | 0 | 2050 | 850 | 1650 | N | 700 | 61 | 76 | 5200 |
JX250SM | 42 | 35 | 67 | 1 | 1 | 0 | 2050 | 850 | 1650 | N | 650 | 60 | 75 | 5400 |
JX260SM | 42 | 35 | 79 | 1 | 1 | 0 | 2050 | 850 | 1650 | N | 700 | 72 | 90 | 6100 |
JX360SM | 42 | 35 | 79 | 1 | 1 | 0 | 2050 | 850 | 1650 | N | 750 | 72 | 90 | 6200 |
JX375SM | 54 | 2*28 | 2*67 | 1 | 2 | 2 | 2300 | 1000 | 1650 | N | 1100 | 90 | 113 | 8000 |
JX390SM | 54 | 2*28 | 2*67 | 1 | 2 | 2 | 2300 | 1000 | 1650 | N | 1150 | 108 | 135 | 9400 |
JX4100SM | 54 | 3*28 | 3*54 | 1 | 3 | 3 | 3900 | 1100 | 1700 | Y | 1250 | 120 | 150 | 10800 |
JX3105SM | 54 | 3*28 | 3*67 | 1 | 3 | 3 | 3200 | 1100 | 1700 | Y | 1300 | 138 | 173 | 12000 |
JX4120SM | 54 | 3*28 | 3*67 | 1 | 3 | 3 | 3900 | 1100 | 1700 | Y | 1450 | 144 | 180 | 12400 |
JX3120SM | 54 | 3*28 | 3*67 | 1 | 3 | 3 | 3400 | 1100 | 1750 | Y | 1400 | 166 | 208 | 13900 |
JX4140SM | 54 | 3*35 | 3*67 | 1 | 3 | 3 | 3900 | 1100 | 1750 | Y | 1600 | 184 | 230 | 16200 |
JX3150SM | 54 | 4*28 | 4*54 | 1 | 4 | 4 | 3400 | 1200 | 1750 | Y | 1600 | 216 | 270 | 16700 |
JX4160SM | 54 | 4*28 | 4*54 | 1 | 4 | 4 | 4100 | 1100 | 1750 | Y | 2000 | 221 | 276 | 18500 |
JX5175SM | 67 | 4*28 | 4*67 | 1 | 4 | 4 | 4700 | 1100 | 1750 | Y | 2000 | 230 | 288 | 20200 |
JX4200SM | 67 | 5*28 | 5*67 | 1 | 5 | 5 | 4100 | 1200 | 1750 | Y | 2200 | 288 | 360 | 22200 |
JX6210SM | 67 | 5*28 | 5*67 | 1 | 5 | 5 | 5300 | 1100 | 1800 | Y | 2500 | 276 | 345 | 24200 |
JX5250SM | 67 | 6*35 | 6*67 | 1 | 6 | 6 | 4700 | 1200 | 1800 | Y | 2500 | 360 | 450 | 27800 |
JX6300SM | 67 | 7*35 | 7*67 | 1 | 7 | 7 | 5300 | 1200 | 1800 | Y | 3000 | 432 | 540 | 33400 |
