型號 | 壓縮機 | 蒸發-40℃ | 蒸發-37℃ | 蒸發-35℃ | 蒸發-30℃ | 蒸發-25℃ | 蒸發-20℃ | ||||||||
匹數 | 型號 | 數量 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | 制冷量 | 功率 | |
JX220SL | 20 | 4PES-12 | 2 | 7.01 | 7.66 | 9.80 | 8.54 | 11.30 | 9.20 | 16.30 | 10.92 | 21.60 | 12.78 | 28.00 | 14.78 |
JX224SL | 24 | 4NES-14 | 2 | 8.50 | 9.20 | 11.90 | 10.42 | 14.00 | 11.26 | 20.50 | 13.44 | 27.10 | 15.70 | 35.60 | 18.02 |
JX230SL | 30 | 4HE-18 | 2 | 12.06 | 11.71 | 14.62 | 13.56 | 18.20 | 14.78 | 25.40 | 17.82 | 34.00 | 20.78 | 45.10 | 23.70 |
JX240SL | 40 | 4GE-23 | 2 | 13.20 | 14.33 | 17.20 | 16.44 | 20.36 | 17.90 | 29.30 | 21.48 | 39.60 | 24.92 | 52.20 | 27.78 |
YX345SL | 45 | 4HE-18 | 3 | 17.60 | 17.50 | 22.00 | 20.34 | 26.55 | 22.17 | 37.50 | 26.73 | 51.00 | 31.17 | 67.60 | 35.55 |
JX250SL | 50 | 6HE-28 | 2 | 16.80 | 17.55 | 22.90 | 20.34 | 26.84 | 22.20 | 39.90 | 26.74 | 51.60 | 31.20 | 68.10 | 35.88 |
JX360SL | 60 | 4GE-23 | 3 | 20.10 | 21.31 | 26.20 | 24.66 | 30.40 | 26.85 | 43.10 | 32.22 | 59.10 | 37.38 | 78.20 | 41.67 |
JX375SL | 75 | 6HE-28 | 3 | 25.20 | 26.30 | 33.10 | 30.51 | 39.36 | 33.30 | 56.60 | 40.11 | 76.20 | 46.80 | 101.30 | 53.37 |
JX390SL | 90 | 6GE-34 | 3 | 30.10 | 31.99 | 39.20 | 36.99 | 45.40 | 40.29 | 65.40 | 48.36 | 88.20 | 56.07 | 117.20 | 62.40 |
JX4100SL | 100 | 6HE-28 | 4 | 34.00 | 36.10 | 44.90 | 40.68 | 52.60 | 44.40 | 73.90 | 53.48 | 101.00 | 62.40 | 135.10 | 71.16 |
JX3120SL | 120 | 6FE-44 | 3 | 37.10 | 39.02 | 48.00 | 44.76 | 56.25 | 48.60 | 79.20 | 58.26 | 105.90 | 67.80 | 140.10 | 77.10 |
JX4120SL | 120 | 6GE-34 | 4 | 39.10 | 42.66 | 51.20 | 49.32 | 60.10 | 53.72 | 85.70 | 64.48 | 116.80 | 74.76 | 155.10 | 83.20 |
JX4160SL | 160 | 6FE-44 | 4 | 19.20 | 52.50 | 63.30 | 59.68 | 74.30 | 64.80 | 104.80 | 77.68 | 141.10 | 90.40 | 186.50 | 102.80 |
JX5200SL | 200 | 6FE-44 | 5 | 61.20 | 65.10 | 79.20 | 74.60 | 92.40 | 81.00 | 130.90 | 97.10 | 176.52 | 113.00 | 233.20 | 128.50 |
JX6240SL | 240 | 6FE-44 | 6 | 73.10 | 78.20 | 95.20 | 89.52 | 111.20 | 97.20 | 156.80 | 116.52 | 211.20 | 135.60 | 278.90 | 154.20 |
型號 | 機組對外管路尺寸 | 標準支管理球閥數量 | 外形尺寸 | 電子低液位報警 | 重量 | 電氣參數 | 機房通風量 | |||||||
排氣 | 供液 | 吸氣 | 排氣 | 供液 | 吸氣 | 長 | 寬 | 高 | 最大工作電流 | 保險絲電流 | m³/h | |||
mm | mm | mm | mm | mm | mm | mm | mm | mm | 有N/無N | kg | ||||
JX220SL | 16 | 12 | 42 | 1 | 1 | 0 | 1450 | 850 | 1700 | N | 500 | 35 | 44 | 1000 |
JX224SL | 16 | 12 | 42 | 1 | 1 | 0 | 1450 | 850 | 1700 | N | 500 | 42 | 53 | 1200 |
JX230SL | 16 | 16 | 54 | 1 | 1 | 0 | 1450 | 850 | 1700 | N | 600 | 53 | 66 | 1600 |
JX240SL | 22 | 16 | 54 | 1 | 1 | 0 | 1450 | 850 | 1700 | N | 600 | 62 | 78 | 1800 |
JX345SL | 22 | 22 | 67 | 1 | 1 | 0 | 2050 | 850 | 1700 | N | 850 | 79 | 99 | 2400 |
JX250SL | 22 | 22 | 67 | 1 | 1 | 0 | 2050 | 1100 | 1750 | N | 800 | 78 | 98 | 2400 |
JX360SL | 28 | 22 | 79 | 1 | 1 | 0 | 2050 | 850 | 1700 | N | 850 | 92 | 115 | 2800 |
JX375SL | 35 | 2*22 | 2*54 | 1 | 2 | 2 | 3200 | 1100 | 1750 | Y | 1100 | 117 | 146 | 3500 |
JX390SL | 35 | 3*22 | 3*54 | 1 | 3 | 3 | 3200 | 1100 | 1750 | Y | 1200 | 138 | 173 | 4200 |
JX4100SL | 35 | 3*22 | 3*54 | 1 | 3 | 3 | 4100 | 1100 | 1750 | Y | 1400 | 156 | 195 | 4700 |
JX3120SL | 42 | 3*22 | 3*54 | 1 | 3 | 3 | 3400 | 1200 | 1750 | Y | 1400 | 177 | 221 | 5100 |
JX4120SL | 42 | 3*22 | 3*54 | 1 | 3 | 3 | 4100 | 1100 | 1750 | Y | 1650 | 184 | 230 | 5600 |
JX4160SL | 54 | 4*22 | 4*54 | 1 | 4 | 4 | 4100 | 1200 | 1750 | Y | 1800 | 235 | 294 | 6800 |
JX5200SL | 54 | 4*28 | 4*67 | 1 | 4 | 4 | 4700 | 1200 | 1800 | Y | 2200 | 294 | 368 | 8500 |
JX6240SL | 54 | 5*28 | 5*67 | 1 | 5 | 5 | 5300 | 1200 | 1800 | Y | 2800 | 353 | 441 | 10100 |
